A man adjusts ZEISS binoculars mounted on a tripod in a foggy, wooded outdoor setting.
蔡司自然观察

蔡司Pro系列三脚架套装

实现可靠的稳定性和精确的调节。
Carbon fiber tripod with adjustable legs and a fluid pan head, designed for professional camera support, shown on a white background.

蔡司专业系列轻型三脚架套装

蔡司专业系列三脚架套装 LIGHTWEIGHT 在稳定性和重量之间实现了完美平衡,是旅行者的理想之选。重量轻、结构紧凑、安装快捷,是鸟类和野生动物观察的理想之选。



Carbon fiber tripod with adjustable legs and a fluid pan head, designed for ZEISS optical equipment.

蔡司专业系列轻型三脚架套装

蔡司专业系列通用三脚架套件可确保在任何情况下都能保持最佳稳定性。适用于双筒望远镜、聚光镜、相机和其他用于野生动物观察、摄影或数码瞄准的设备。



Two ZEISS tripods standing on a grassy field with a forested background in soft natural light.

卓越的稳定性

  • 坚固的 10 层碳纤维支腿
  • 经过优化的支腿截面直径
    (通用型 36 - 32 - 28 毫米/轻量型 28 - 25 - 22 毫米)
  • 经过优化的橡胶脚垫,可就地固定
  • 加大了第一支腿角度,增强了稳定性(24°)。
Close-up of a person adjusting the height of a tripod leg in an outdoor setting with foggy trees in the background.

快速简便的设置

  • 3 节式支腿设计 - 兼顾紧凑性和快速安装
  • 加长型扭锁,可轻松、安静地调节支腿
  • 可拆卸的穿心立柱,便于调节高度
  • 多个易于设置的支腿角度(24、55 和 85°) - 单手可调
Professional tripod with a fluid video head and ZEISS branding on a white background.

安全连接

  • Arca-Swiss 安装系统
  • 扩展适配器板,带橡胶防滑条和安全销用于非 Arca-Swiss 光学系统
Close-up of a professional tripod head with ZEISS branding set up outdoors on a grassy background.

蔡司液压云台

  • 完美设计的平衡系统可实现平稳移动和精确调节,即使在高倍放大时也是如此
  • 经过放大的、人体工学设计的杰出控制装置可确保即使戴着手套也能舒适直观地使用
  • 伸缩式手柄可延长并安装在两侧,以便左右手均可使用
ZEISS camera tripod kit with carrying case, tripod, mounting accessories, tools, and instruction manuals laid out on a white background.

套件包括哪些内容?

  • 三脚架包
  • 脚管包
  • 脚钉
  • 加长适配器板
  • 短中轴
  • 工具箱

技术参数

ZEISS Pro-Series Tripod Kits
  • Leg Tube Diameters

    28 mm | 25 mm | 22 mm

    Weight (With Head)

    2.1 kg | 4.6 lbs

    Maximum Height

    176 cm | 69.3")

    Maximum Height (With Center Column Down)

    135 cm | 53.1"

    Compressed Size (Including Head)

    68.5 cm | 27.0"

    Maximum Load

    40 kg | 88 lbs

    Leg Angles

    24° | 55° | 85°

    Leg Sections

    3

    Locking Mechanism

    Twist Lock

    Center Column

    Extendable and Detachable

    Arca-Swiss Compatibility

    +

    Adapter Plate

    +

    Water Level

    3

  • Leg Tube Diameters

    36 mm | 32 mm | 28 mm

    Weight (With Head)

    2.8 kg | 6.2 lbs

    Maximum Height

    186 cm | 73.2")

    Maximum Height (With Center Column Down)

    160 cm | 63.0"

    Compressed Size (Including Head)

    77.5 cm | 30.5"

    Maximum Load

    60 kg | 132 lbs

    Leg Angles

    24° | 55° | 85°

    Leg Sections

    3

    Locking Mechanism

    Twist Lock

    Center Column

    Extendable and Detachable

    Arca-Swiss Compatibility

    +

    Adapter Plate

    +

    Water Level

    3

保修期为10年。

注册三脚架后,您将自动激活我们的十年保修服务。

匹配的灯头和配件

蔡司专业系列三脚架

Black ZEISS tripod head with a precision ball joint, pan handle, and quick-release mounting plate.
Black ZEISS tripod head with a precision ball joint, pan handle, and quick-release mounting plate.

球形云台 V-60

蔡司专业系列球形云台 V-60 用途极为广泛,可提供多种俯仰角度和复合调整。倾斜角度最大可达 115°,平稳而精确,让您每次都能找到完美的角度。云台移动阻力可轻松调整,以适应各种安装设备的不同重量,而可伸展的控制手柄则增加了长时间使用时的舒适度。

Black ZEISS tripod ball head with adjustment knobs, mounting plate, and leveling indicators.
Black ZEISS tripod ball head with adjustment knobs, mounting plate, and leveling indicators.

球形云台 L-55

蔡司专业系列球形云台 L-55 是一款流行、可靠、稳定的球形云台。它采用熟悉的低调设计,可为所安装的设备提供高达 90° 的总调节角度。该云台操作流畅,调节精确,可轻松为所安装的光学器件或设备找到最佳位置。

Black ZEISS tripod head with a built-in handle grip and quick-release plate attachment.
Black ZEISS tripod head with a built-in handle grip and quick-release plate attachment.

调平头 Q-75

Q-75调平头提供快速访问功能。它兼容Arca-Swiss标准,并配备75毫米适配器。单手柄调节装置配有延长挂钩,使用更便捷。

Black padded neck strap with adjustable side straps and a central ZEISS logo on the front.
Black padded neck strap with adjustable side straps and a central ZEISS logo on the front.

配件包

蔡司配件包的设计目的是增加三脚架的重量,以提高稳定性,尤其是在大风天气或使用较重设备时。它也是临时存放额外设备的实用解决方案。

Precision camera mounting rail system with integrated spirit level and adjustable components, featuring the ZEISS logo.
Precision camera mounting rail system with integrated spirit level and adjustable components, featuring the ZEISS logo.

多设备轨道

蔡司多设备导轨是一款多功能配件,可让您同时将多台设备安装在三脚架云台上。兼容Arca-Swiss和1/4-20接口标准,能稳固安装测距仪、观测镜、双筒望远镜、热成像设备等各类器材。这使其成为最大化提升三脚架系统功能与效率的理想解决方案。

Black ZEISS mounting clamp with adjustable knob and serrated gripping jaws, designed for secure attachment.
Black ZEISS mounting clamp with adjustable knob and serrated gripping jaws, designed for secure attachment.

望远镜适配器

蔡司双筒望远镜适配器可快速方便地将双筒望远镜安装到三脚架上。它采用 Arca-Swiss 接口,可确保与三脚架云台的安全连接。其设计提供了舒适的握把,使操作和控制更加轻松自如。该适配器与以下蔡司望远镜兼容: 蔡司 SFL、蔡司 Conquest HDX、蔡司 Conquest HD、蔡司 Terra ED 42。

Black ZEISS-branded optical instrument accessory with ergonomic grip and adjustment knob, standing upright on a flat base.
Black ZEISS-branded optical instrument accessory with ergonomic grip and adjustment knob, standing upright on a flat base.

三脚架望远镜适配器 1/4-20

蔡司三脚架转双筒望远镜适配器1/4-20可快速便捷地将双筒望远镜固定于三脚架上。其配备的Arca-Swiss接口确保与三脚架云台的稳固连接,人性化握持设计带来轻松操控体验。本适配器兼容以下蔡司双筒望远镜型号:ZEISS Victory SFLZEISS Conquest HDXZEISS Conquest HDZEISS Terra ED 42。

Black ZEISS camera mounting clamp with textured grip surfaces, adjustment knob, and central screw hole.
Black ZEISS camera mounting clamp with textured grip surfaces, adjustment knob, and central screw hole.

步枪夹具

蔡司步枪固定夹提供简便、快速且稳固的步枪固定方案。它能确保步枪在各种射击场景中保持稳定性、追踪性能及精准射击定位。符合人体工学的旋钮设计提升了握持感与调节控制力,进一步保障步枪获得安全可靠的支撑。此外,用户在野外需要固定或支撑特定物品时,亦能发现此配件具有多重实用价值。
